Specification:

ATX 12V 2.3

Form factor:

SFX

Efficiency:

>85%

Dimension (DxWxH):

100 mm x 125 mm x 64 mm

PFC:

Active (0,9)

Fan dimension:

80mm silent fan

Performance

AC Input:

230V / 3A

Frequency:

50 Hz

+5V:

15A

+3,3V:

14A

+5V & +3,3V combined:

80W

+12V 1:

18,5A / 220W

+12V 2:

N/A

+12V 1 & +12V 2 combined:

N/A

+12V 3:

N/A

+12V 4:

N/A

+12V 3 & +12V 4 combined:

N/A

P.F.:

>0,9

-12V:

0,3A / 3,6W

+5VSB:

3A / 15W

Maximum Load:

250W

Connectors

Native cable:

20+4PIN:

===300mm===[20+4PIN]

SATA:

===300mm===[SATA]===150mm===[SATA]

Molex/Floppy:

===300mm===[Molex]===150mm|===[Molex]===150mm===[Floppy]

4PIN 12V:

===300mm===[4PIN 12V]
