ASUS LCD 24.1" PA24AC 1920x1200 16:10 ProArt IPS 100% sRGB HDR 400 DP over USB-C-VIDEO+60W DP HDMI USB3.0
Popis a parametry
ASUS LCD 24.1" PA24AC 1920x1200 16:10 ProArt IPS 100% sRGB HDR 400 DP over USB-C-VIDEO+60W DP HDMI USB3.0
https://www.asus.com/Monitors/PA24AC/
Display
Panel Size: Wide Screen 24.1"(61.13cm) 16:10
Color Saturation : 100%(sRGB)
Panel Type : IPS
True Resolution : 1920x1200
Display Viewing Area(HxV) : 518.4 x 324 mm
Brightness : 350 cd/? (Typical)/400 cd/? (Peak)
Contrast Ratio : 1000 :1 (Typical)/8000 :1 (HDR)
ASUS Smart Contrast Ratio (ASCR) : 100000000:1
Viewing Angle (CR?10) : 178°(H)/178°(V)
Response Time : 5ms (Gray to Gray)
Display Colors : 16.7M (real 8 bit)
Flicker free
LCD ZBD Warranty : Yes
Dynamically Local Dimming : Yes, 4 Zones
Video Feature
Trace Free Technology : Yes
SPLENDID Video Preset Modes : 8 Modes (sRGB Mode/Rec. 709 Mode/Scenery Mode/Standard Mode/User Mode 1/User Mode 2/Reading Mode/Darkroom Mode)
Color Temperature Selection : 4 Modes
Color Accuracy : ?E< 2
Gamma adjustment : Yes (Support Gamma 1.8/2.0/2.2/2.4/2.6 )
Color Adjustment : 6-axis adjustment(R,G,B,C,M,Y)
QuickFit (modes) : Yes (A4/B5/Alignment Grid/Ruler/Customization Modes)
Picture-in-Picture : Yes
Picture-by-Picture : Yes
Low Blue Light : Yes
HDCP support : Yes, 1.4 & 2.2
Adaptive-Sync supported :Yes
HDR (High Dynamic Range) Support :Yes
Audio Features
Stereo Speakers : 2W x 2 Stereo RMS
I/O Ports
Signal Input : HDMI(v2.0a) x2, DisplayPort 1.2, USB Type-C
Earphone jack : 3.5mm Mini-Jack
USB upstream : USB3.0 Type-C x1
USB downstream : USB3.0 Type-A x4
Signal Frequency
Digital Signal Frequency : 30 ~85 KHz (H) /48 ~70 Hz(V)
Power Consumption
Power On (Typical): < 21W*
Power Saving Mode : < 0.5W ; Power Off Mode : 0W (Hard Switch)
100-240V, 50/60Hz
Mechanical Design
Chassis Colors : Gray
Tilt : -5°~+23°
Swivel : -45°~+45°
Pivot : -90°~+90°
Height Adjustment : 0~110 mm
VESA Wall Mounting : 100x100mm
Frameless Design : Yes
Quick Release Stand Design : Yes
Security
Kensington lock
Dimensions
Phys. Dimension with Stand (WxHxD) : 532 x (378-488) x 202 mm
Phys. Dimension without Stand (WxHxD) : 532 x 349 x 55 mmBox Dimension (WxHxD) : 650 x 260 x 430 mm
Weight
Net Weight (Esti.) : 6.5 kg
Net Weight Without Stand (Esti.) : 4.28 kg
Gross Weight (Esti.) : 9 kg
Accessories
Power cord
DisplayPort cable
USB-C cable
USB-C to A cable
Quick start guide
HDMI cable
Warranty Card
Color pre-calibration report
Cable Clip
Compliance and Standards
Energy Star®, BSMI, CB, CCC, CE, CEL level , CU, ErP, FCC, ISO-9241-307, J-MOSS, KCC, Mac Compliance, PSE, RoHS, TCO7.0, UkrSEPRO, UL/cUL, VCCI, WEEE, WHQL (Windows 10, Windows 8.1, Windows 7), MEPS, TUV Flicker-free , KC , eStandby, TUV Low Blue Light, Vietnam MEPS, ICES-3, RCM, VESA DisplayHDR 400
Note
*HDCP2.2 for HDMI and DisplayPort ports
*Adaptive-Sync for HDMI and DisplayPort ports
*HDR-10 by HDMI / DisplayPort ports. HDR performance requires compatible monitors, streaming devices, video graphic cards, OS and playback software for PC devices or media players which all support HDR function.
.
Display
Panel Size: Wide Screen 24.1"(61.13cm) 16:10
Color Saturation : 100%(sRGB)
Panel Type : IPS
True Resolution : 1920x1200
Display Viewing Area(HxV) : 518.4 x 324 mm
Brightness : 350 cd/? (Typical)/400 cd/? (Peak)
Contrast Ratio : 1000 :1 (Typical)/8000 :1 (HDR)
ASUS Smart Contrast Ratio (ASCR) : 100000000:1
Viewing Angle (CR?10) : 178°(H)/178°(V)
Response Time : 5ms (Gray to Gray)
Display Colors : 16.7M (real 8 bit)
Flicker free
LCD ZBD Warranty : Yes
Dynamically Local Dimming : Yes, 4 Zones
Video Feature
Trace Free Technology : Yes
SPLENDID Video Preset Modes : 8 Modes (sRGB Mode/Rec. 709 Mode/Scenery Mode/Standard Mode/User Mode 1/User Mode 2/Reading Mode/Darkroom Mode)
Color Temperature Selection : 4 Modes
Color Accuracy : ?E< 2
Gamma adjustment : Yes (Support Gamma 1.8/2.0/2.2/2.4/2.6 )
Color Adjustment : 6-axis adjustment(R,G,B,C,M,Y)
QuickFit (modes) : Yes (A4/B5/Alignment Grid/Ruler/Customization Modes)
Picture-in-Picture : Yes
Picture-by-Picture : Yes
Low Blue Light : Yes
HDCP support : Yes, 1.4 & 2.2
Adaptive-Sync supported :Yes
HDR (High Dynamic Range) Support :Yes
Audio Features
Stereo Speakers : 2W x 2 Stereo RMS
I/O Ports
Signal Input : HDMI(v2.0a) x2, DisplayPort 1.2, USB Type-C
Earphone jack : 3.5mm Mini-Jack
USB upstream : USB3.0 Type-C x1
USB downstream : USB3.0 Type-A x4
Signal Frequency
Digital Signal Frequency : 30 ~85 KHz (H) /48 ~70 Hz(V)
Power Consumption
Power On (Typical): < 21W*
Power Saving Mode : < 0.5W ; Power Off Mode : 0W (Hard Switch)
100-240V, 50/60Hz
Mechanical Design
Chassis Colors : Gray
Tilt : -5°~+23°
Swivel : -45°~+45°
Pivot : -90°~+90°
Height Adjustment : 0~110 mm
VESA Wall Mounting : 100x100mm
Frameless Design : Yes
Quick Release Stand Design : Yes
Security
Kensington lock
Dimensions
Phys. Dimension with Stand (WxHxD) : 532 x (378-488) x 202 mm
Phys. Dimension without Stand (WxHxD) : 532 x 349 x 55 mmBox Dimension (WxHxD) : 650 x 260 x 430 mm
Weight
Net Weight (Esti.) : 6.5 kg
Net Weight Without Stand (Esti.) : 4.28 kg
Gross Weight (Esti.) : 9 kg
Accessories
Power cord
DisplayPort cable
USB-C cable
USB-C to A cable
Quick start guide
HDMI cable
Warranty Card
Color pre-calibration report
Cable Clip
Compliance and Standards
Energy Star®, BSMI, CB, CCC, CE, CEL level , CU, ErP, FCC, ISO-9241-307, J-MOSS, KCC, Mac Compliance, PSE, RoHS, TCO7.0, UkrSEPRO, UL/cUL, VCCI, WEEE, WHQL (Windows 10, Windows 8.1, Windows 7), MEPS, TUV Flicker-free , KC , eStandby, TUV Low Blue Light, Vietnam MEPS, ICES-3, RCM, VESA DisplayHDR 400
Note
*HDCP2.2 for HDMI and DisplayPort ports
*Adaptive-Sync for HDMI and DisplayPort ports
*HDR-10 by HDMI / DisplayPort ports. HDR performance requires compatible monitors, streaming devices, video graphic cards, OS and playback software for PC devices or media players which all support HDR function.
.
ParametryPorovnání
Formát obrazovky
16:10
Rozlišení displeje
1920x1200
Povrchová úprava displeje
Matný
Rozhraní
DisplayPort
Rozhraní
HDMI
Rozhraní
3.5mm Jack
Výbava
Reproduktory
Výbava
Pivot
Výbava
VESA montáž
Výbava
Dokování NTB
Typ panelu
IPS
Úhlopříčka displeje (")
24,1
